Model your project savings and peak-demand reduction
Calculate ROICommercial Energy Audit
Stop guessing where the kWh goes. Our MS 1525-aligned energy audit covers electricity, HVAC, lighting, motors, compressed air, refrigeration, and process heat. Investment-grade report. Bankable savings projection. RM 4,000 – RM 25,000 fixed-fee.
From RM 4,000 walk-through · RM 25,000 investment-grade
Enquire about this service
What we audit
From Level 2 up, major energy end-uses are measured with loggers, not estimated. We identify the real waste, not the textbook waste.
Electricity & Maximum Demand
Baseline kWh and MD (kVA) profiling against TNB tariff blocks. We identify peak demand spikes, poor power factor penalties, and half-hourly load shape to right-size any solar + battery pairing.
HVAC & Chillers
Chiller COP benchmarking, AHU fan speed analysis, cooling tower drift loss, and thermostat setpoint audit. Often around half of a commercial building's electricity use — the highest-return target.
Lighting
Lux-level mapping against MS 1525 recommended illuminance. We calculate kWh savings from LED retrofits, daylight zoning, and occupancy-sensor controls — with a room-by-room payback table.
Motors & Pumps
Load factor and efficiency class assessment for all motors ≥3.7 kW. VSD retrofit sizing, rewound motor efficiency loss estimates, and pump affinity-law savings projections.
Compressed Air
Leak detection (ultrasonic), operating pressure vs. equipment requirement, air receiver sizing, and compressor part-load efficiency. Lowering operating pressure can reduce compressor energy use; the saving depends on the plant.
Refrigeration & Cold Rooms
Refrigerant charge, condenser fouling, evaporator defrost cycle, and door seal integrity checks. Cold room envelope U-value assessment for food & pharma facilities.
3 audit levels — choose your depth
Each level builds on the last. Upgrade to a deeper scope at any point — we credit your earlier engagement fee.
Walk-Through Audit
1-2 days
RM 4,000 – RM 8,000
- Visual inspection of all major energy systems
- Utility bill and tariff benchmarking
- Top 5 Energy Conservation Measures (ECMs) identified
- Indicative savings estimate — not instrumented
- Written report delivered
Suitable for: SMEs under 500 kW MD wanting a quick baseline
Engineering Audit
2-4 week instrumented study
RM 10,000 – RM 18,000
- Data loggers + power quality meters installed
- Half-hourly demand profile captured
- Quantified ECMs with engineering-grade payback
- Solar and battery sizing integrated into analysis
- GITA / MyHIJAU eligibility pre-assessment
Suitable for: Factories and commercial buildings 500 kW – 2 MW
Investment-Grade Audit
4-8 week deep study
RM 18,000 – RM 25,000
- All Level 2 scope plus 4-week continuous logging
- Report structured for green-financing applications (acceptance is the bank's decision)
- ISO 50001 gap analysis included
- Internal rate of return modelled for each ECM
- Supporting documentation for your GITA application
Suitable for: Large C&I facilities seeking green financing or ISO 50001
What you receive
- Baseline kWh + MD demand profile (daily, weekly, monthly)
- Top 10 ranked Energy Conservation Measures with NPV and payback
- Solar and battery sizing recommendation integrated with load curve
- GITA / MyHIJAU / GreenRE incentive eligibility assessment
- 5-year cumulative energy savings projection in Ringgit and tCO₂e
Standards we map to
Our findings are structured so the same data supports multiple certification and incentive frameworks simultaneously.
MS 1525
Malaysian standard on energy efficiency and use of renewable energy in non-residential buildings — our primary benchmark.
MGTC LCCF
Low Carbon Cities Framework & Assessment System — relevant for facilities seeking GreenRE or MyHIJAU certification.
GreenRE
Green Real Estate rating system aligned to MGTC. Our audit evidence can be used in a GreenRE Energy-credit submission.
ISO 50001
International Energy Management System standard. Our Level 3 audit includes a gap analysis to identify what's needed for certification.
How the audit works
Four clear phases from first call to final report. No surprises.
Step 1 — Kick-Off & Data Request
We issue a data request list covering 12 months of TNB bills, equipment schedules, floor plans, and operation hours. A 1-hour kick-off call aligns scope and access logistics.
Step 2 — Site Instrumentation
Our engineers install data loggers, clamp meters, lux sensors, and compressed air leak detectors. For Level 1, this is a visual walk-through only.
Step 3 — Engineering Analysis
We model your baseline energy use, benchmark it against MS 1525 targets, rank ECMs by NPV, and size any solar + battery configuration against your actual demand profile.
Step 4 — Report Delivery & Q&A
Final report delivered in PDF and editable Excel. We present findings to your engineering and finance teams and answer questions in a 90-minute handover session.
Know exactly where your energy budget is going
Many Malaysian facilities pay more on their TNB bill than they need to. A Level 2 audit identifies and prices the energy conservation measures (ECMs) worth implementing first.
